Script 100
This simulates an analog phaser of the past.
Parameter | Value | Explanation |
|---|---|---|
Rate Sync | OFF, ON | If this is ON, the rate synchronizes with the tempo of the rhythm. |
Rate | 0.05–10.00 [Hz] | Frequency of modulation |
Rate Note | ||
Duty | -50–50 | Adjusts the ratio of speeds at which the modulation rises or falls. |
Min | 0–100 | Lower limit reached by modulation |
Max | 0–100 | Upper limit reached by modulation |
Manual Sw | OFF, ON | Applies modulation according to the value of the Manual parameter, rather than modulating automatically. |
Manual | 0–100 | Adjusts the basic frequency from which the sound will be modulated. |
Resonance | 0–66 | Amount of feedback |
Mix | 0–127 | Level of the phase-shifted sound |
Level | 0–127 | Output Level |
