Here’s how to assign functions to a footswitch that’s connected to this device.
- Turn the type knob to “SFX (7)”.
Turn the other knobs besides the type knob all the way clockwise.
While pressing this device’s pedal switch, turn on the power by inserting a plug into the INPUT A (MONO) jack.
The CHECK indicator blinks orange.
Use the [VARIATION] knob to select the function to assign to the footswitch.
[VARIATION] knob
Explanation
1
MOMENTARY/TAP Use this setting when connecting two footswitches or a dual footswitch externally.
The CTL 1 footswitch is assigned to the tap tempo function, and the CTL 2 footswitch is assigned to the momentary switch (*) function.
2
TAP TEMPO Assigns the tap tempo function.
3
MOMENTARY Assigns the momentary switch (*) function for switching the effect on/off.
- A “momentary switch” switches the effect on only while the footswitch is pressed.
When making the settings, you can hear the effect sound from the OUTPUT A (MONO) and OUTPUT B jacks.
Note that the sound that’s output uses the effect settings as they were just before the power on this device was last turned off.
If you’re hearing an effect sound that’s hard to distinguish, set the effect settings to simple settings (such as type knob = “SINGLE (1)”, [VARIATION] knob = “1” and so forth), turn off the device and start again from step 1.
Press this device’s pedal switch.
The settings are saved.
Also, the CHECK indicator rapidly blinks red.
The device can be used normally after around two to three seconds.
